Spring Security Authentication with HTTP Basic

In this section, you will learn about the HTTP basic authentication in Spring Security.  When HTTP basic authentication is configured, web browser will display a login dialog for user authentication.

Required Tools used for this Application:
  • Spring MVC 3.0.1
  • Spring Security 3.1.0
  • STS 2.8.1.RELEASE
  • Tomcat 7
  • Jdk 1.7
 You can configure HTTP basic authentication in sdnext-security.xml as follows :
<?xml version="1.0" encoding="UTF-8"?>
<beans xmlns="http://www.springframework.org/schema/beans"
       xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
       xmlns:security="http://www.springframework.org/schema/security"
       xmlns:p="http://www.springframework.org/schema/p"
       xsi:schemaLocation="http://www.springframework.org/schema/beans
                           http://www.springframework.org/schema/beans/spring-beans.xsd
                           http://www.springframework.org/schema/security
                           http://www.springframework.org/schema/security/spring-security-3.1.xsd">

   <security:http auto-config="true" >
  <security:intercept-url pattern="/index*" access="ROLE_USER" />
  <security:http-basic></security:http-basic>
  <security:logout logout-success-url="/logout" />
 </security:http>

    <security:authentication-manager>
   <security:authentication-provider>
     <security:user-service>
   <security:user name="dineshonjava" password="sweety" authorities="ROLE_USER" />
     </security:user-service>

   </security:authentication-provider>
 </security:authentication-manager>

</beans>
To enable HTTP basic, just change "form-login" to "http-basic" tag. As follows on the above file
<security:http auto-config="true" >
  <security:intercept-url pattern="/index*" access="ROLE_USER" />
  <security:http-basic></security:http-basic>
  <security:logout logout-success-url="/logout" />
 </security:http>

And all remaining code same as the previous example Spring Security form-based login example ,

After that we will run the example.
Running the example

Export the example as war and deploy it Tomcat 7 server. While browsing the project you will get the following screen for login:

Access URL http://localhost:8080/sdnext/index“, Spring will redirect to your custom login form.
URL : http://localhost:8080/sdnext/index


If username/password is correct, authentication success, display requested page.

URL : http://localhost:8080/sdnext/index



Download Source Code + Libs
SpringSecurityHttpBasic.zip



References-
http://www.dineshonjava.com/2013/02/spring-security-form-based-login-example.html
Spring Security
Spring Security documentation
